 HP Z440Workstation


Processor Options:

• Supports single Intel® Xeon® E5-1600 v3/v4 and E5-2600 v3/v4 series processors.

• Processor configurations range from 4-core to 14-core setups, with Hyper-Threading support allowing two threads per core.

• Memory:

• Equipped with 8 DIMM slots supporting up to 128 GB of DDR4 ECC Registered SDRAM.

• Memory speeds up to 2400 MHz, ensuring efficient multitasking and application performance.

• Storage Options:

• Multiple storage configurations available, including:

• SATA HDDs ranging from 500 GB to 4 TB (7200 rpm).

• SAS drives up to 1.2 TB (10000 rpm) or 600 GB (15000 rpm).

• SATA SSDs up to 1 TB.

• HP Z Turbo Drive G2 PCIe SSDs up to 1 TB for faster data access and improved system responsiveness.

• Graphics Support:

• Compatible with a range of professional graphics cards, including:

• NVIDIA® Quadro® series (e.g., K4200, M2000).

• AMD FirePro™ series (e.g., W2100).

• These options cater to various levels of graphical workloads, from entry-level to high-end 3D rendering and simulations.

• Expansion and Connectivity:

• Offers multiple PCIe slots for expansion, including:

• 2 PCIe x16 Gen3 slots.

• 1 PCIe x8 Gen3 slot.

• Additional PCIe and PCI slots for various expansion cards.

• Front I/O ports include 4 USB 3.0 ports (with one charging port), 1 microphone jack, and 1 headset jack.

• Rear I/O ports feature 4 USB 3.0 ports, 2 USB 2.0 ports, 2 PS/2 ports, 1 RJ-45 (NIC), and audio line-in/out ports.
